Опис
| Вхід (PV) | |
| Max. PV Input Power | 7,5kW |
| Max. PV Input Voltage | 600V |
| Start-up Voltage | 100V |
| Rated Voltage | 360V |
| MPPT Voltage Range | 100V ~ 550V |
| Number of MPP Trackers | 2 |
| Number of MPP Trackers / String per MPPT | 1/ 1 |
| Max. Current per MPPT | 16A |
| Max. Short Circuit Current per MPPT | 24A |
| Вихід (AC) | |
| Max. Output Current | 22,7A |
| Rated Output Power | 5kW |
| Max. Output Power | 5,5kVA |
| Rated Voltage | 230V |
| Frequency | 50Hz / 60Hz |
| Power Factor | 0.8 lagging~0.8 leading |
| THDi | <3% |
| Вихід (EPS) | |
| Max. Output Power | 5kW |
| Max. Output Current | 22.7A |
| Peak Output Power，Time | 7kW, 10s |
| Rated Voltage，Frequency | 230V/50Hz |
| Automatic Switch Time | <10ms |
| THDV | <3% |
| Батарея | |
| Battery Type | Lithium, Lead-acid |
| Battery Voltage Range | 40V ~ 60V |
| Max. Charge / Discharge Current | 100A |
| Communication | CAN |
| Ефективність | |
| Max. Efficiency | 97.50% |
| European Efficiency | 97.20% |
| Battery Charge / Discharge Efficiency | 95.00% |
| Захист | |
| DC Switch | YES |
| DC Reverse Polarity Protection | YES |
| Anti-islanding Protection | YES |
| AC Short Circuit Protection | YES |
| Residual Current Monitoring | YES |
| Insulation Resistance Monitoring | YES |
| Ground Fault Monitoring | YES |
| Over Current / Voltage Protection | YES |
| Battery Soft Start Protection | YES |
| Surge Protection | Type II |
| AFCI Protection | Optional |
| Моніторінг | |
| Display | LCD |
| Communication | RS485 / CAN / WIFI / 4G / LAN / Bluetooth |
| Відповідність стандартам | |
| Certificates | IEC/EN 62109-1/2, IEC/EN 61000-6-1/3, IEC61727/IEC62116 |
| EN50549, CEI0-21, C10/C11, VDE4105, VDE0126, G98/99 | |
| RD244, UNE217001, UNE217002, AS4777, NRS097-2-1 | |
| Загальні дані | |
| Dimensions (W x H x D) | 481x 390x 200 mm |
| Weight | 21kg |
| Operation Temperature | -30℃ ~ +60℃ |
| Cooling Method | Natural |
| Protection Degree | IP66 |
| Noise Emission | <25dB |
| Max. Operating Altitude | 4000m |
| Relative Humidity | 0 ~ 100% |
| Topology | High Frequency Insolation (For battery) |
| Standby Power Comsuption | ＜10W |
