Опис
| Вхід (PV) | |
| Max. PV Input Power | 7kW |
| Max. PV Input Voltage | 550V |
| MPPT Voltage Range | 125V ~ 500V |
| Max. PV Input Current | 14A |
| Number of MPP Trackers / String per MPPT | 2 / 1 |
| Вихід (AC) | |
| Max. Output Current | 26A |
| Rated Output Power | 6kW |
| Max. Output Power | 6kVA |
| Rated Voltage | 230V, L + N + PE |
| Operating Voltage Range | 176V ~ 270V |
| Frequency | 50Hz / 60Hz |
| Power Factor | 0.8 lagging~0.8 leading |
| THDi | <3% |
| Вихід (EPS) | |
| Rated Power | 6kW |
| Rated Voltage | 230Vac |
| Rated Current | 26A |
| Rated Frequency | 50Hz / 50Hz |
| Automatic Switch Time | <20ms |
| Overload Capability | 110%, 30s / 120%, 10s / 150%, 0,02s |
| THDV | <2% |
| Батарея | |
| Battery Voltage Range | 40V ~ 58V |
| Max. Charge Voltage | 58V |
| Charge / Discharge Current | 95A / 110A |
| Battery Type | Lithium / Lead-acid |
| Communication | CAN / RS485 |
| Ефективність | |
| Max. Efficiency | 97.60% |
| European Efficiency | 97.00% |
| MPPT Efficiency | 99.90% |
| Battery Charge / Discharge Efficiency | 95.00% |
| Моніторінг | |
| Display | LCD / LED |
| Communication | RS485 / CAN / DRM / optional: WIFI / 4G |
| Відповідність стандартам | |
| Certificates | CE, TUV, SAA, NRS |
| Загальні дані | |
| Operation Temperature | -25℃ ~ +60℃ |
| Cooling Method | Natural |
| Protection Degree | IP65 |
| Noise Emission | <35dB |
| Max. Operating Altitude | 2000m |
| Relative Humidity | 0 ~ 95% (non-condensing) |
| Topology | Transformerless |
| Standby Power Comsuption | ＜3W |
