Опис
| Вхід (PV) | |
| Max. PV Input Power | 8kW |
| Max. PV Input Voltage | 550V |
| Start-up Voltage | 140V |
| MPPT Voltage Range | 120V ~ 500V |
| Max. PV Input Current | 13.5A |
| Max. Short Circuit Current per MPPT | 15A |
| Number of MPP Trackers / String per MPPT | 2 / 1 |
| Вихід (AC) | |
| Max. Output Current | 26A |
| Rated Output Power | 6kW |
| Max. Output Power | 6kVA |
| Rated Voltage | 230V, L + N + PE |
| Operating Voltage Range | 180V ~ 270V |
| Frequency | 50Hz / 60Hz |
| Power Factor | 0.8 lagging~0.8 leading |
| THDi | <3% |
| Вихід (EPS) | |
| Max. Output Power Without Solar | 4kW |
| Max. Output Power With Solar | 6kW |
| Rated Voltage | 230Vac |
| Rated Current | 17.4A |
| Rated Frequency | 50Hz / 50Hz |
| Automatic Switch Time | 10ms |
| Peak Power Without Solar | 4500W，30s |
| THDV | <5% |
| Батарея | |
| Battery Voltage Range | 40V ~ 60V |
| Nominal Battery Voltage | 48V |
| Max. Charge Voltage | 59V |
| Charge / Discharge Current | 80A / 80A |
| Battery Type | Lithium / Lead-acid |
| Ефективність | |
| Max. Efficiency | 97.90% |
| European Efficiency | 97.50% |
| Battery Charge / Discharge Efficiency | 94.50% |
| Моніторінг | |
| Display | LCD / LED |
| Communication | RS485 / CAN / WiFi |
| Відповідність стандартам | |
| Certificates | CEI0-21, EN50549 , IEC62109-1/2, IEC61000 |
| Загальні дані | |
| Dimensions (W x H x D) | 455 x 476 x 181 mm |
| Weight | 20kg |
| Operation Temperature | -25℃ ~ +60℃ |
| Cooling Method | Natural |
| Protection Degree | IP65 |
| Noise Emission | <25dB |
| Max. Operating Altitude | 4000m |
| Relative Humidity | 0 ~ 100% |
| Topology | Transformerless |
| Standby Power Comsuption | ＜5W |
